HD67871-A1-4A: IO-Link Master / EtherNet/IP slave - Converter

Ports:

1xEthernet; 4xIO-Link;

Ethernet protocol

EtherNet/IP Slave

IO-Link protocol

IO-Link Master

Data rates EtherNet/IP

10/100 Base-T Autosensing

Data rates IO-Link

4800 bps - 38400 bps - 230400 bps

EtherNet/IP Connector

RJ45

IO-Lin Connector

4x-IO-Link A: 4way 3mm terminal block

Power Supply Connector

2way 5mm terminal block

Power Supply

8..24V AC; 12..35V DC

Operating temperature

-40° to +85° (-40°F to +185°F)

Dimensions

120x23x107 (LxWxH)

Weight

200g approx

Mechanical fixing

DIN Rail montage

SOFTWARE:

SW67871
