HD67439-E7V: J1939 / CAN - Converter

Ports:

1xCAN; 1xJ1939

Data Rates J1939

Up to 1 Mbps

Data Rates CAN

Up to 1 Mbps

J1939 Connector

3way SuperSeal 1.5

CAN Connector

3way SuperSeal 1.5

Power Supply Connector

2way SuperSeal 1.5

Power Supply

10..40V DC; 8..26V AC

Operating temperature

-40°C/+105°C (-40°F/+221°F)

Dimensions without fixing lugs

76x86x40 (LxWxH)

Dimensions with fixing lugs A

105x86x40 (LxWxH)

Dimensions with fixing lugs B

83x112.5x40 (LxWxH)

Dimensions with fixing lugs C

105x112.5x40 (LxWxH)

Weight

200g approx

Software

SW67439
